BF-5000 SERIES BARRIER-FREE DUAL WALL MOUNT DRINKING FOUNTAIN

Lustrous satin-finish stainless steel satisfies the criteria for cleanliness and easy care in medical centers and office buildings. Push button control located on front panel. Vandal resistant bottom plate and mounting plate are standard. Beveled front with or without back plate.

-FP are frost proof models.

It is recommended that a dual check valve backflow prevention be installed in the waterline going to any FP fountain.

Product Number for the BARRIER-FREE S. STEEL WALL MOUNTED FOUNTAINS:

BF-5000, BF-5000-FP (Two level with back plate)

BF-5020, BF-5020-FP (Single with back plate)

BF-5040, BF-5040-FP (Single with front push button)

​​Product number corresponds to dimensions tab below. Select your product number to fit the space you need

OPTIONS:

-RV | Reverse heights

BFCA-1 | Cane Touch Apron

Mounting plate comes standard

Access plates are vandal resistant and provide easy maintenance

Push button valve on front

Adjustable flow regulation

18 gauge brush finished stainless steel receptor with a vandal resistant chrome plated brass drain plug

Stainless steel supply fittings connected to reinforced tubing

In-line mesh screen strainer

Attractive, protective stainless steel back plate

Supply complete with 1/2” IPS lock shield screwdriver stop

1-1/4” IPS waste pipes included with every fountain

BF-5000 14-7/8″H x 35″W with 18-1/2″ extension

BF-5020 9-5/8″H x 19″W with 18-1/2″ extension

BF-5040 7″H x 12″W with 18″ extension

All dimensions subject to manufacturing variance of plus or minus 1/4″ (6 mm).
