SINGLE WALL MOUNT DRINKING FOUNTAIN
Striking design with clean, sleek lines. Designed to defy the elements, resist vandals and stand up to hard use. The chrome-plated brass bubbler is locked to the stainless steel receptor. Push button valve is vandal resistant and recessed in steel plate. Vandal resistant bubbler guard.
ADA Compliant
-FP are frost proof models.
It is recommended that a dual check valve backflow prevention be installed in the waterline going to any FP fountain
Product Number for the SINGLE WALL MOUNTED DRINKING FOUNTAINS:
5300, 5300-FP (Front mount)
5305, 5305-FP (Rear mount)
Options:
FLWMP-1 | Support carrier with mounting plate (5300)
FLWMP-1-FM | Support carrier with mounting plate (5305)
WMP-1 | Mounting plate (5300)
WMP-1-FM | Mounting Plate (5305)
-SS | Stainless steel finish
Mounting plate and stainless steel bottom plate come standard
Access plates are vandal resistant and provide easy maintenance
Push button chrome plated brass valve recessed in 3/8” steel plate
Steel bubbler guard(s) and chrome plated brass bubbler
Adjustable flow regulation
Heavy 3/8” sheet steel arm
18 gauge brush finished stainless steel receptor with a vandal resistant chrome plated brass drain plug
Stainless steel supply fittings connected to reinforced tubing
Woodland green powder coat finish with optional colors and stainless steel (-SS) available
In-line mesh screen strainer
Attractive, protective stainless steel back plate
Supply complete with 1/2” IPS lock shield screwdriver stop
1-1/4” IPS waste pipes included with every fountain
5300 8″H x 20″ L / Wall mounted
5305 8″H x 20″ L / Wall mounted
All dimensions subject to manufacturing variance of plus or minus 1/4″ (6 mm).
5300_5305_Spec_04:24
