WDA-3600, WDA-3610, WDA-3620

Ramp Type

Product Details

PARIAN RAMP TYPE / Three sides flanged*
WDA-3600 - WDA-3620
Terrazzo's natural non-slip surface provides better footing and increased safety. Wheelchair shower floors are flanged on three sides for a water tight joint between the wall and shower floor. These shower floors must be set on a level grout or mortar bed. The intent is to allow a wheelchair patient to lift one’s self onto a transfer seat with the assistance of a grab bar. This transfer type shower floor has an integral cast 12” ramp with a stainless steel cap that covers and protects the leading 6” of the ramp. A floor drain by others at the entrance to the sloped threshold and a collapsible water dam (Option: -RDM) are recommended for added protection. NOTE: * Note: Flanges are intended to be used with wall tile applied by others to conform with Federal, state and local shower stall dimensions. Floors can be supplied less flanges (-LF). Dimensions WDA-3600 - 39x39" WDA-3610 - 60x30" WDA-3620 - 60x36" Download File(s) WDA-3600-3620 (PDF) / WDA-3600-3660 (RFA)
